Product Description:
This one is professional suitcase portable High power mobile phone jammer for Cellphone 5G 3G 4GLTE/WIMAX Wi-Fi2.4G/5G GPS LOJACK UHF VHF Signal Jammer which are currently presented on the market. Build-in battery can works 1.5 hours.Build-in AC adapter non-stop working, Hidden or open the omni antennas for hanheld used. Also can customize for High power drone jammer model with 4-6 directional antennas which bring us a strong jamming ability to defend 100% drones UAVs up to 1000 meters.
Basic Specifications
Model: NT-CJ12S
Color: Black
Block Signal Type: 2G GSM CDMA DCS 3G 4G 5G WIFI2.4G WIFI5G GPS UHF VHF Signals
Output Power:Total 86W,3-10W each band
Jammer Radius:10-80 meters
Power Supply:AC110-240V to DC27V
Cooling System:High efficiency aluminum alloy radiator+ 3X cooling fans
Working Time:Not-stop Working(Build-in AC power DC27V or External Battery 24V10Ah working 1.5hours)
Product Size:465x365x185mm
Product Weight: appr.12kg ( for OMNI antennas)
| Key technical specifications: Suitcase Portable Mobile Phone Signal Jammer NT-CJ12S |
| Channel |
Output Port |
Frequency range |
Average out-putting power(±1dBm) |
| 1 |
GSM or CDMA |
925-960 or 851-894MHz |
40dbm / 10W |
| 2 |
DCS or PCS |
1805-1880 or 1920-2000MHz |
39dbm / 8W |
| 3 |
3G |
2110-2180MHz |
39dbm / 8W |
| 4 |
4GLTE |
738-821 or 700-803MHz |
40dbm / 10W |
| 5 |
4G WIMAX |
2500-2690 MHz |
39dbm / 8W |
| 6 |
WIFI2.4G or 4G2300 |
2400-2500 or 2300-2400MHz |
39dbm / 8W |
| 7 |
5G600 or 5G1500 |
617-698 or 1427-1518MHz |
40dbm / 10W |
| 8 |
5G3500/3700 |
3400-3800MHz |
37dbm / 5W |
| 9 |
GPSL1 |
1570-1610MHz |
37dbm / 5W |
| 10 |
GPSL2L3L4L5 |
1170-1390MHz |
37dbm / 5W |
| 11 |
VHF/LOJACK |
135-175MHz |
37dbm / 5W |
| 12 |
WIFI5G |
5125-5850MHz |
35dbm / 3W |
| Option |
UHF/RC433 |
400-470MHz |
37dbm / 5W |
| RC315 |
310-330MHz |
37dbm / 5W |
Power supply: AC adapter 50 to 60Hz, (AC110 or 240V-DC12V)
Build-in Battery:24V10Ah Working Time:1.5Hours |
| Dimension: (length,width, height ) 465 x 365 x 185 mm |
Package Size: 540 x500 x 270mm
N.W:11.5kg
G.W:=15kg
Working temperature: -30~60ºC |
Total power:86W
Shielding radius: (10--80) meters At -75dBm
Still depends on the strength signal in given area
Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
| Warranty: one year from delivery date |
Advantage:
Output power total 86w, shielding 10-80m,Still depends on the strength signal in given area.
Each unit can jam up to 12 frequency bands simultaneously, each frequency band is separate and with adjustable power from max to off
3 pieces cooling fans, not-stop to work with build-in AC adapter
Also build-in Battery 24V10Ah or more, continue working 1.5 hours,
Battery Power and charger stative display via LED screen
Hidden or open the omni antennas for hanheld used
Suitcase portable design, option to external battery using,too.
Package Contents:
Jammer Host x 1,
antenna x12,
AC Plug x1,
Battery Charge x1,
External Battery Cable x1.
OEM Customized Service
Silkscreen OEM service can be offered.
Application
o It can be applied at meeting rooms, conference rooms, museums, galleries, theatres, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus and more Places that require silence, confidentiality and information security.
